how to build a \u0026lt;- google_ad_section_start -> Computers \u0026lt;- google_ad_section_end -> Computer viruses The handwritten assembling of computers has several advantages such as the hardware components are freely selectable and one on the PC consult,.
gamers have, for example, the most powerful hardware and must therefore be even more money on the table, what is worth but also (
The fastest computer ever painted by the customer, only for Commodore Gaming
) to get hardware which are focused on games.
For ordinary consumers or for the office you need simpler hardware is also cheaper then.
Now I want you here an illustrated guide to building a functioning computer to write.
Another good shop is this:
COMBAT READY! specializes in overclocking PCs 5 year warranty!
What is needed? To add a computer
to build, they need the following hardware components: first
Housing
second Mainboard
third Video card
4th Memory
5th CPU / CPU fan
6th Computer power supply
7th CD / DVD drive or burner
8th Disk
In selecting the components must be ensured that the parts fit together to compare the product descriptions, for example, if the motherboard has an AM2 socket, the cpu also be AM2.
are in this picture to see all the parts needed.
Step 1 Preparing the body:
At first, they should lie down all the things clear, so that everything is easily accessible.
they take the computer case and screw seen from the front left side plate. Lay the case with the now open side on.
in the housing should be to pour a bag of bolts have been with them all of them in a container in order to better get to the screws to it.
take the panel change for the rear ports of the motherboard box and the case-mounted visor. (They make sure that the diaphragm is the right way so that the connections fit properly at the end)
Here is again the aperture and the open case to see:
Now they take the screws that were with the housing there and look for small screws that serve as a spacer from the case to the motherboard.
Now compare the screw in case back with those on the Main Board.
screw the standoffs into the case (the motherboard is still out there).
If, in the case, no power supply is integrated, they have a fit, this is usually made up in the back corner of the enclosure.
is now preparing the body finished.
Take it step by 2 continued.
2, the Main Board Preparation:
2.0 RAM
Use any material or foam pad and place it on the motherboard.
RAM (memory and cpu cpulüfter must be connected).
At first, the memory can be connected, to press the sticks simply plug in the pews.
Make sure that the stick is the right way round this might not fit.
They must also note that the latch is properly engaged.
2.1 CPU and CPU fan
The use of a CPU (processor) must be very careful that no pins to break off the bottom otherwise breaks the cpu.
down to the bottom of the cpu in the socket is a small gold corner is seen on the base is also a corner marked sure that when the corners are aligned. Here
Images:
Here the cpu from below the mark can be seen in the red circle.
This is the base where the cpu down inside the two marked corners will have to lie to each other. To be the cpus must use a small lever on the edge of the base are folded down inside the cpu and the lever pressed down again.
Now the cpu if not applied to the fan base with a cooling paste flatter they are used to the heat of the cpu can be derived better. On the job, press a small dollop of cooling paste on the cpu and spread it with the fingers evenly on it. That put the fan I can not tell them exactly, since the receiving each motherboard is slightly different. Depends on the fan always turn a cable, which is the power connector on the motherboard and is directly next to the cpu socket the plug receptacle.
The board is now ready prepared to continue with step 3.
composed step 3.
Now taking the prepared Motherboard and put it in as clean the case, the holes in the motherboard to the standoffs of the housing and screw the motherboard are laid out.
then connect the front lines of the case to the motherboard
as the plugs are inserted from the main board on the pins is described in the manual of the motherboard but I do have a few pictures.
front USB connections
other features such as front desk.
If this is to be done by connecting the power supply to the motherboard can be produced.
seek them out to the wide connector from the wire harness the power adapter and plug it into the socket of the motherboard (which looks like) is
now in the cable bundle or a square plug which they must connect with the motherboard.
In order to install the CD / DVD drive in your computer, remove the front panel,
by clinging to the image the viewer pressed together (there are usually 3) Remove the front
and easy. take
now and turn out the metal grille under the front panel and plug the drive into the inside frame and screw it tight, then the housing front, only slipped yet again.
The drive is now with the Motherboard and power connected. for most modern drives, this SATA connectors are there is not much to note because they fit in only one direction in the motherboard and drive. Attention must be among older people that bending any connector pins or cancel each.
framework now needs to the hard drive in that is simply pushed into the intended space, and bolted to the mother board and electricity are connected.
are in this picture to see the SATA ports.
are here to see the older IDE ports, which are with me, unfortunately, been broken off or bent.
I hope you could help with this guide Assemble your computer successfully.
MFG
Markus
